Solar module mounting structure manufacturer · Hyderabad

Solar structures made in Hyderabad, designed for the wind where they'll stand.

Greentek Vasistron roll-forms galvanised C, Z and U sections, punches them for bolt-together assembly, and engineers each ground, roof or carport table to the site's own wind and soil data. Nothing is welded on site.

Send a layout or call +91 93478 15712

On this page Terra ground mount Aero carport & canopy Tecta rooftop & shed Engineering design basis The works Dhulapally

IS 875 Pt.3 wind design
[IS 800] steel design
GI [275] gsm · HDG to IS 4759
SS304 fasteners
No site welding
[x] tonnes of structure a month
[25]-year structural warranty

01 · Ground mount

SolBase Terra

Fixed-tilt ground mount tables on driven posts or ballast, designed to the soil report and the site wind zone.

Foundation: Driven post [1.5–2.0] m embedment, or PCC ballast Selected from the soil report
Tilt: [15–30]° fixed; seasonal-adjust option
Module layout: 2P / 3P portrait, [12–24] modules per table Any module up to [2.4] m length

SolBase Terra specifications and datasheet

SolBase Terra: Ground mount — Two- and three-portrait fixed-tilt tables for open land and industrial parks. Post spacing, embedment and member sizes come from the site data, not a catalogue default.

02 · Carport & canopy

SolBase Aero

Cantilever and portal carport structures that turn parking, walkways and loading bays into generating roof.

Foundation: RCC pedestal with anchor bolts Pedestal design supplied
Tilt: [5–10]° Drainage inside the rafter
Module layout: Landscape or portrait, [2–4] rows per frame

SolBase Aero specifications and datasheet

SolBase Aero: Carport & canopy — Hot-rolled columns on RCC pedestals with cold-formed rafters, drainage inside the rafter, and vehicle clearances set from your site plan.

03 · Rooftop & shed

SolBase Tecta

Rooftop structures for metal sheet, RCC and elevated installations, with the existing roof checked before we quote.

Roof types: Trapezoidal sheet, standing seam, RCC flat, RCC with parapet
Fixing: SS304 self-drill screws or clamps on sheet; anchor fasteners on RCC
Tilt: Flush on sheet; [10–15]° tilt-up on RCC

SolBase Tecta specifications and datasheet

SolBase Tecta: Rooftop & shed — Mini-rail brackets that clamp to sheet crests without piercing the trough, rail and clamp systems on RCC, and tilt-up frames where the roof pitch needs correcting.

04 · Custom

Custom structures

When a standard table does not fit, we design one that does. Same GI sections, same fasteners, same IS 875 design basis.

Custom structures

Engineering · design basis

Every table is designed to the site, then the design report ships with the steel.

Basic wind speed and terrain from IS 875 Part 3, member checks to [IS 800], IS 2062 steel, coating to IS 277 or IS 4759. The report lists the wind pressure, the section sizes and the foundation loads, so your consultant can check it.

Read the design basis

SolBase Terra · 2P fixed tilt · section A-Anot to scale
